| MECHANICAL DATA |
| Actuator/keys | 4 keys (Left+right mouse key+Scrolling key+DPI adjustable key) |
| Key Switch Technology | Micro switch + plastic mouse buttons |
| Key Lifespan | ≤3 millions actuation |
| Actuation Force | 0.55±0.15N |
| Key Gram Force | 50±10gf |
| Resolution | 400-800-1200-1600DPI |
| Actuation Pressure | 1.0N-2.0N |
| Rotary Encoder Lifespan | ≥0.8 millions scrolling |
| G.W. | 0.25KGs |
| ELECTRICAL DATA |
| Supply Voltage | DC +5V±5% |
| Current Rating | ≈80mA |
| Meet MIL-STD-461G (EMC, EMI, EMS, ESD) |
| 1 | CE101 25Hz - 10kHz Conducted Emissions, Audio Frequency Currents, Power leads |
| 2 | CE102 10kHz -10MHz Conducted Emissions, Radio Frequency Potentials, Power leads |
| 3 | CS101 25Hz - 150kHz Conducted Susceptibility, Power Leads |
| 4 | CS106 Conducted Susceptibility, Transients, Power Leads |
| 5 | CS112 Electrostatic Discharge Susceptibility |
| 6 | CS114 4kHz -400MHz Conducted Susceptibility, Bulk Cable injection |
| 7 | CS115 Conducted Susceptibility, Bulk Cable injection, Impulse Excitation |
| 8 | CS116 10kHz - 100MHz Conducted Susceptibility, Damped Sinusoidal Transients, Cables and Power Leads |
| 9 | RE101 25Hz -100kHz Radiated Emissions, Magnetic Field |
| 10 | RE102 10kHz - 18GHz Radiated Emissions, Electric Field |
| 11 | RS101 25HZ - 100kHz Radiated Susceptibility, Magnetic Field |
| 12 | RS103 10kHz - 40GHz Radiated Susceptibility, Electric Field |
| MIL-STD-810F (wide temperature, shock, salt mist, vibration, fungus, humidity etc.) |
| Lifespan | > 5 years |
| Interface | USB, other interfaces can be customized |
| OS | All Windows, Linux, Unix, Mac OSX, Vxworks, Android, (U-cos--To be confirmed). |
| ENVIRONMENTAL ADAPTABILITY |
| Operating temperature | -40℃ to +55℃ |
| Storage temperature | -45℃ to +60℃ |
| Operating RH | 95% |
| Atmospheric pressure | 60-106Kpa |
| Saline mist | 96 hours, IEC 60512-6 |
| Damp heat test at +40℃ | 21 days, IEC 60512-6 |
| Dry heat test at +85℃ | 10 days, IEC 60512-6 |
| RELIABILITY |
| RoHS Compliant, CE and FCC, MIL-STD-461G (EMC, EMI, EMS, ESD) and MIL-STD-810F (wide temperature, shock, salt mist, vibration, fungus, humidity etc.) |
| Protection Level | IP68 |
| MTBF | >20000H |
| MTTR | <30min |
| APPLICATION | Industrial, Vehicle, aerospace, naval, defense, maritime, Radar, console, portable rugged laptop, UAV ground station, GCS, medical and pharmaceutical etc. |
